Percona Monitoring Plugins 1.1.6 release

Percona is glad to announce the release of Percona Monitoring Plugins 1.1.6.

Changelog:

  • Added new RDS instance classes to RDS scripts.
  • Added boto profile support to RDS scripts.
  • Added AWS region support and ability to specify all regions to RDS scripts.
  • Added ability to set AWS region and boto profile on data source level in Cacti.
  • Added period, average time and debug options to pmp-check-aws-rds.py.
  • Added ability to override Nginx server status URL path on data source level in Cacti.
  • Made Memcached and Redis host configurable for Cacti script.
  • Added the ability to lookup the master’s server_id when using pt-heartbeat with pmp-check-mysql-replication-delay.
  • Changed how memory stats are collected by Cacti script and pmp-check-unix-memory.
    Now /proc/meminfo is parsed instead of running free command. This also fixes pmp-check-unix-memory for EL7.
  • Set default MySQL connect timeout to 5s for Cacti script. Can be overridden in the config.
  • Fixed innodb transactions count on the Cacti graph for MySQL 5.6 and higher.
  • Fixed –login-path option in Nagios scripts when using it along with other credential options.

Thanks to contributors: David Andruczyk, Denis Baklikov, Mischa ter Smitten, Mitch Hagstrand.

The project is fully hosted on Github now including issues and Launchpad project is discontinued.

A new tarball is available from downloads area or in packages from our software repositories. The plugins are fully supported for customers with a Percona Support contract and free installation services are provided as part of some contracts. You can find links to the documentation, forums and more at the project homepage.

Percona Monitoring PluginsAbout Percona Monitoring Plugins
Percona Monitoring Plugins are monitoring and graphing components designed to integrate seamlessly with widely deployed solutions such as Nagios, Cacti and Zabbix.

Read more at: http://www.mysqlperformanceblog.com/

Percona Server 5.5.47-37.7 is now available

Percona Server 5.5.47-37.7
Percona is glad to announce the release of Percona Server 5.5.47-37.7 on January 12, 2016. Based on MySQL 5.5.47, including all the bug fixes in it, Percona Server 5.5.47-37.7 is now the current stable release in the 5.5 series.

Percona Server is open-source and free. Details of the release can be found in the 5.5.47-37.7 milestone on Launchpad. Downloads are available here and from the Percona Software Repositories.

Bugs Fixed:

  • Running OPTIMIZE TABLE or ALTER TABLE without the ENGINE clause would silently change table engine if enforce_storage_engine variable was active. This could also result in system tables being changed to incompatible storage engines, breaking server operation. Bug fixed #1488055.

Other bugs fixed: #1179451, #1524763, and #1530102.

Release notes for Percona Server 5.5.47-37.7 are available in our online documentation. Bugs can be reported on the launchpad bug tracker.

Read more at: http://www.mysqlperformanceblog.com/

Percona Server 5.6.28-76.1 is now available

Percona Server 5.6.28-76.1Percona is glad to announce the release of Percona Server 5.6.28-76.1 on January 12, 2016. Download the latest version from the Percona web site or from the Percona Software Repositories.

Based on MySQL 5.6.28, including all the bug fixes in it, Percona Server 5.6.28-76.1 is the current GA release in the Percona Server 5.6 series. Percona Server is open-source and free – and this is the latest release of our enhanced, drop-in replacement for MySQL. Complete details of this release can be found in the 5.6.28-76.1 milestone on Launchpad.

Bugs Fixed:

  • Clustering secondary index could not be created on a partitioned TokuDB table. Bug fixed #1527730 (DB-720).
  • When enabled, super-read-only option could break statement-based replication while executing a multi-table update statement on a slave. Bug fixed #1441259.
  • Running OPTIMIZE TABLE or ALTER TABLE without the ENGINE clause would silently change table engine if enforce_storage_engine variable was active. This could also result in system tables being changed to incompatible storage engines, breaking server operation. Bug fixed #1488055.
  • Setting the innodb_sched_priority_purge variable (available only in debug builds) while purge threads were stopped would cause a server crash. Bug fixed #1368552.
  • Small buffer pool size could cause XtraDB buffer flush thread to spin at 100% CPU. Bug fixed #1433432.
  • Enabling TokuDB with ps_tokudb_admin script inside the Docker container would cause an error due to insufficient privileges even when running as root. In order for this script to be used inside Docker containers this error has be been changed to a warning that a check is impossible. Bug fixed #1520890.
  • InnoDB status will start printing negative values for spin rounds per wait, if the wait number, even though being accounted as a signed 64-bit integer, will not fit into a signed 32-bit integer. Bug fixed #1527160 (upstream #79703).

Other bugs fixed: #1384595 (upstream #74579), #1384658 (upstream #74619), #1471141 (upstream #77705), #1179451, #1524763 and #1530102.

Release notes for Percona Server 5.6.28-76.1 are available in the online documentation. Please report any bugs on the launchpad bug tracker .

Read more at: http://www.mysqlperformanceblog.com/

Play the Percona Powerball Pool!!

percona powerball

percona powerballThe Only Sure Thing is Percona Powerball Pool

Everyone is talking about the upcoming Powerball lottery draw. 1.4 BILLION dollars!! And growing! Millions of people are imagining what they would do IF they win. It’s the stuff of dreams.

That is literally true. The chances of winning the Powerball Lottery are 1 in 292.2 million. Or roughly speaking, the chances of picking the right combination of numbers is like flipping a coin and getting heads 28 times in a row. You’re more likely to get struck by lightning (twice) or bitten by a shark.

Sorry.

You know what is a sure thing? Percona’s ability to optimize your database performance and increase application performance. Our Support and Percona Care consultants will give you a 1 in 1 chance of making your database run better, solving your data performance issues, and improving the performance of your applications.

However, in the spirit of moment, Percona has bought 10 sets of Powerball numbers and have posted them on Facebook, Twitter and LinkedIn. It’s the Percona Powerball Pool! Like either post and share it, and you are qualified for one (1) equal share of the winnings! Use #perconapowerball when you share.

Here are the numbers:

percona powerball

We at Percona can’t promise a huge Powerball windfall (in fact, as data experts we’re pretty sure you won’t win!), but we can promise that our consultants are experts at helping you with your full LAMP stack environments. Anything affecting your data performance – on that we can guarantee you a win!

Full rules are here.

Read more at: http://www.mysqlperformanceblog.com/

Prometheus as an Engine for MySQL Monitoring

prometheusWhen I first discovered Graphite years ago, I was very impressed with its monitoring capabilities.  Compared to many RRD-based tools that were popular at the time (like Cacti), Graphite separated the captured data and graphs, allowing you to do all kinds of math and transformations while visualizing data. For example, I could plot the relationship between system queries and disk IO, and capture how the system was getting more IO bound over time. It also had reasonably high performance, allowing me to capture high-resolution data for medium-sized systems.

Just last year I discovered Prometheus, and it also impressed me. I think it has the potential to take Graphite’s flexibility to the next level. Though I am in no way a Prometheus expert, I  want to share my understanding and thoughts on it so far.

Data Model

The data model is perhaps what attracted me to Prometheus the most. While it’s not obvious at first, when you do figure it out it has fantastic flexibility.

In the data model used by Whisper and Carbon in Graphite, you will use something like this to store MySQL data:

myapp.store.mysql.db01.status.questions = 5000

You can set up any hierarchy you like, but it has to have a hierarchy.

What Prometheus does instead is allow you to use a set of key-value pairs. The same data shown above could be presented like this:

questions_total{app=”myapp”,subsystem=”store”,engine=”mysql”,host=”db01”, source=”status”} = 5000

(You most likely wouldn’t use this exact structure, but it’s good for illustration.)

The difference between these approaches it that Prometheus provides you multiple dimensions on which you can filter and aggregate, plus you can add those dimensions later as you need them (without needing to redesign your tree hierarchy).

These labels are very dynamic, and I can change them in a second. For example, a MySQL server reporting as a “Master” might start reporting as a “Slave” in the very next second, and its data will be aggregated differently.

This is especially important in the modern, often cloud-based and virtualized world. For example, using Prometheus it is very easy to tag servers by their region or availability zones. I can also do things like compute MySQL space usage by both the database and storage engine. The possibilities are endless.

Data Capture

Unlike Graphite – where the main model is push and the hosts themselves choose what kind of information they want to push to monitoring system and at which intervals – with Prometheus you set up “Exporters” that have the ability to export the data. It is up to the Prometheus server configuration to choose what data to sample and how frequently.

The clear benefit of Prometheus’ approach is that you can have as many servers as you like pulling the data, so it is very easy to create a development version of your system and play around with it – without affecting production. It also provides a simple pathway to high availability.

(Both the push and pull approaches have their benefits and drawbacks. Brian Brazil wrote an excellent article advertising the pull model of monitoring.)

Prometheus does create a few challenges for me. Unless I want to set up Service Discovery, it is a hassle to monitor any development/test VMs I might spin up (that would otherwise not be open to external access at all). While this isn’t the main use case for Prometheus, it is helpful for me to test the dashboard’s behavior with different operating systems, workloads, etc.

A more significant issue I discovered is dealing with some data that can’t be captured to multiple locations, because the data capture causes the data to change.

Here is specific example: if I look at the

events_statements_summary_by_digest

 table in

PERFORMANCE_SCHEMA

, there is a

MAX_TIMER_WAIT

 field that shows me what the maximum query execution time is for the query pattern. If I want to get the maximum query execution time for every minute, for example, I would need to “truncate” the table to reset the statistics and let the maximum value be computed again. If I don’t perform that operation, the data becomes meaningless. If I make the exporter to reset the statistics during the poll, however, I can’t pull it from two Prometheus servers.

This is one instance where Prometheus’ performance schema design could be better. I could set up a Cron job or Event to clear out the statistics regularly and get a  proper maximum value for every five minutes, but that isn’t an overly convenient solution.

Another issue I discovered is that Prometheus doesn’t have any protection from bad (long) samples, or a very good method of detecting of them. Let’s imagine that I have a MySQL server and I’m sampling status data every second. For some reason the call to

SHOW GLOBAL STATUS

 took five seconds to execute. The truth is we don’t really know where in those five seconds the

SHOW GLOBAL STATUS

 output corresponds – it might be at very start, it might be at the very end. As such, you don’t really know how to process the counters. Whatever you do, you’re likely to be wrong. My preference in this case it to simply discard such samples, because even missing one percent of the samples is unlikely to change the whole picture. Constantly questioning whether you really had a couple of seconds where the QPS spiked to ten times the normal rate, or that it’s an invalid sample, is not something I on which I want to waste a lot of time!

My preferred approach is to configure the

SHOW GLOBAL STATUS

 capture so that if it takes more than ten percent of the capture interval, it will be discarded. For example, with a one second capture I would allow 100ms for the capture. If the system is not keeping up with this scale, I would be better to not fool myself and reduce the capture resolution to around five seconds.

The only protection Prometheus allows is to configure the scrape_timeout, but unfortunately it is only limited to one second resolution at this point. This is too coarse for any high-resolution capture.

Finally, it is also inconvenient to specify different resolutions for different data. In MySQL there is a often a lot of data that I want to capture, but the resolution needed for each capture is different. For example,

SHOW GLOBAL STATUS

 with one second resolution is must. At the same time, capturing the table size information from

INFORMATION_SCHEMA

 with a one second resolution would put too much load on MySQL, especially if there are a lot of tables. That level of resolution in this case isn’t really needed.

An attractive thing about Prometheus is that the Prometheus development team uses it a lot for MySQL monitoring, so the MySQL Exporter is really good. Most MySQL monitoring plugins I find resort to reporting just a few basics statistics, which is not nearly enough for advanced diagnostics. The Prometheus MySQL exporter gets tons of stuff and has been adding more in every version.

I also very much like that the Prometheus Exporters are designed using HTTP protocol. This means it is very easy to debug or see what kind of data they capture. They present it simply using a web-browser:

HTTP browser

Computational Model

I think the basic operations in Prometheus are pretty intuitive, but if you look at some of the advanced behaviors you’re going to find some inconveniences and some things that are likely to surprise you.

One inconvenience is that Prometheus is mainly designed for working with high resolution data. If there are more than five minute holes (by default) in the time series, they could disappear from the graphs. As I mentioned, for MySQL there is quite a lot of information that it makes sense to capture at a resolution lower than five minutes.

Prometheus functions are looking in the “past,” and designed in a way that the value of the function at any time (T) when it could be computed is not going to change. It all looks clean and logical, but it causes issues with holes in the data capture.

As an example, let’s imagine following five seconds where the total number of questions from the start successfully scrapped some seconds but not others (due to a network issue, overload, etc.):

1  –  10
2  –  20
3  –  X
4  –  X
5  –  200

 When we capture data of “counter” type the most important value it has is not the actual counter value at the given time but the rate of change of the counter at different time intervals. If in this case, for example, the query rate was ten QPS for intervals one through two seconds, this can be clearly computed. But what was the query rate in the three through four second interval? We don’t really have exact data, but that is fine: we know there have been 180 queries during the two through five second interval, giving us 60 QPS (which we can use for the three through four seconds interval).

This is NOT, however, how Prometheus will compute it if you use a high irate() function (which is suppose to give you highest resolution possible). When you evaluate irate() at T=4, it doesn’t have access to the T=5 value, even if it is in the database. Instead, it will look back and find the matching previous interval (one through two) and use the corresponding value of ten QPS.

I find this pretty puzzling and inconvenient.

There is also the rate() function, which can be used to get the average rate for the period.  Unfortunately it can’t estimate the rate for a smaller period based on the available data for a longer period. So for example if I ask rate() function to compute a query rate at T=4, looking one second back, it will return no data. This isn’t a big deal when you’re working with data manually, but if you’re building zoomable dashboards it means you can zoom in to the point where the data will disappear (rather than stopping at the best possible value available).

Storage

Prometheus has its own high performance storage system which is based in part on LevelDB. It is highly optimized for time series and can achieve a very high level of compression. Be ready, though: all your label combinations will create a different time series on the low level, and will require a lot of files. This isn’t really a problem with SSD drives and modern file systems, but it something to look out for.

The capture engine and storage systems are rather efficient. Even though Prometheus does not have built in clustering for “scaling out,” you can reportedly get more than 300K metrics per second captured on a single node. You can also use multiple Prometheus servers as needed.

The problem I found with Prometheus’ storage is that it is very self contained: you can only use it from Prometheus or access it from the HTTP API. There are no tools at this point to export it for advanced analysis with R, or to dump the whole database into something like JSON format so it can be loaded into a different database engine. Some of these features might already be on roadmap.

Purging and Aggregation

Retention configuration in Prometheus is pretty spartan. You can set

storage.local.retention

 to the length you want to store the data, but that’s it. You can’t configure it to purge different data at different times. You can run multiple Prometheus instances to achieve this, but it’s quite a hassle.  It’s also not possible to instruct Prometheus to automatically build summaries in order to execute low resolution queries faster.

For example if I have MySQL’s query rate captured every second, but I want to view the data over a long time period (e.g., how it changed over last three months to estimate growth trends), data aggregated at hour intervals would be enough for that purpose.

There is support for recording rules to help achieve some of this, but it is not explicit or convenient in my opinion.

Looking at the Prometheus roadmap, some of these issues might not be fixed in Prometheus but achieved through integrating other systems such as InfluxDB (where experimental support already exists).

Purpose

A lot of these limitations make sense if you look at the purpose for which Prometheus was created: getting high-resolution data and being able to provide as much troubleshooting information as possible to its Alerting engine. It is not really designed for storing extensive history. Too bad! I would very much like to get both of those properties in the single system!

Visualization

As you install Prometheus, it has a built-in Expression Browser, which is great for debugging and interactive analyses. It also allows you to see what data you actually have in the database. It will disappoint you, however, if you’re looking for beautiful graphs!

HTTP installer

This shows I have the information about MySQL query rate from two servers, as well as the available and configured labels.

If I want to pick one server and look at the average rate of queries per five minutes, I can do this:

HTTP graphs

There are some tools available in the graph to chose the time range and resolution.

You should aware that visualizing data with the rate() function often shows you things that do not exist. In this case, it looks like the number of queries was gradually creeping up. In reality, I just started the benchmark so the number of queries jumped almost immediately. This is what the real situation looks like (using irate()):

HTTP graphs 2

As I explained before, irate() does not handle missing data points very well, plus it behaves somewhat bizarrely when you “zoom out” – providing instant rate information at sparse intervals (e.g., the instant rate computed every one second over 60 seconds) rather than smoothing things to averages.

There is also the PromDash tool available for Prometheus, which gives you nicer looking dashboards and supports a lot of Prometheus’ features. Now that Grafana has official support for Prometheus, it is my preferred tool to build dashboards – especially since it supports multiple data sources besides Prometheus.

Summary

I’m very excited about Prometheus. It allows me to get a lot of information easily and use it for Performance analyses in benchmarking or troubleshooting. It would be great if it also had a simple integrated solution for long term storage and trending. I am also looking forward to better integration with Grafana and better documentation on how to create Prometheus-based dashboards – especially with some Prometheus-based examples!

Note: All above was written about Prometheus 0.16.1. Prometheus is rapidly evolving and may  change with newer versions.

Read more at: http://www.mysqlperformanceblog.com/

OpenSSH CVE-2016-0777: Details and Mitigation

OpenSSH

OpenSSHEarlier today advisories were sent out regarding OpenSSH versions 5.4 through 7.1., informing users about a security bug in the software. In essence, the advisory instructed people to add the

UseRoaming no

 option to their ssh_config file, with a promise for further information to be made available shortly.



The post on the security issue at OpenBSD Journal can be seen here: http://undeadly.org/cgi?action=article&sid=20160114142733

This information was then later released detailing the issue and the implications here: http://www.openssh.com/txt/release-7.1p2

The statement below summarized the main issue:

The matching server code has never been shipped, but the client code was enabled by default and could be tricked by a malicious server into leaking client memory to the server, including private client user keys.”

So what does this all mean? Simply speaking, this means a malicious or compromised server could potentially retrieve the users private SSH keys from memory. The stolen keys could then be used to authenticate against servers.

(2FA helps to protect servers from the use of stolen keys, however this is not in as widespread use as it should be.)

The short summary is in lieu of an update to the software, you can use the following mitigation options to protect yourself:

  1. In your ~/.ssh/config:
    Host * UseRoaming no
  2. In your ssh_config:
    Linux: /etc/ssh/ssh_config OSX: /private/etc/ssh/ssh_config
  3. On each CLI execution:
    ssh -oUseRoaming=no <hostname>



Personally, I’ve used a combination of 1 and 2, as often a ~/.ssh/config cleanup is required. Make sure and check that your OpenSSH is correctly configured, and keep watching for updates.

Read more at: http://www.mysqlperformanceblog.com/

Making Apache Spark Four Times Faster

Apache SparkThis is a followup to my previous post Apache Spark with Air ontime performance data.

To recap an interesting point in that post: when using 48 cores with the server, the result was worse than with 12 cores. I wanted to understand the reason is was true, so I started digging. My primary suspicion was that Java (I never trust Java) was not good dealing with 100GB of memory.

There are few links pointing to the potential issues with a huge HEAP:

http://stackoverflow.com/questions/214362/java-very-large-heap-sizes
https://blog.codecentric.de/en/2014/02/35gb-heap-less-32gb-java-jvm-memory-oddities/

Following the last article’s advice, I ran four instances of Spark’s slaves. This is an old technique to better utilize resources, as often (as is well known from old MySQL times) one instance doesn’t scale well.

I added the following to the config:

export SPARK_WORKER_INSTANCES=4
export SPARK_WORKER_CORES=12
export SPARK_WORKER_MEMORY=25g

The full description of the test can be found in my previous post Apache Spark with Air ontime performance data

The results:
Apache Spark

Although the results for four instances still don’t scale much after using 12 cores, at least there is no extra penalty for using more.

It could be that the dataset is just not big enough to show the setup’s full potential.

I think there is a clear indication that with the 25GB HEAP size, Java performs much better than with 100GB – at least with Oracle’s JDK (there are comments that a third-party commercial JDK may handle this better).

This is something to keep in mind when working with Java-based servers (like Apache Spark) on high end servers.

Read more at: http://www.mysqlperformanceblog.com/

Dealing with corrupted InnoDB data

MySQL

MySQLData corruption! It can happen. Maybe because of a bug or storage problem that you didn’t expect, or MySQL crashes when a page checksum’s result is different from what it expected. Either way, corrupted data can and does occur. What do you do then?

Let’s look at the following example and see what can be done when you face this situation.

We have some valuable data:

> select * from t limit 4;
+---+--------+
| i | c      |
+---+--------+
| 1 | Miguel |
| 2 | Angel  |
| 3 | Miguel |
| 4 | Angel  |
+---+--------+
> select count(*) from t;
+----------+
| count(*) |
+----------+
|  2097152 |
+----------+

One day the query you usually run fails and your application stops working. Even worse, it causes the crash already mentioned:

> select * from t where i=2097151;
ERROR 2006 (HY000): MySQL server has gone away

Usually this is the point when panic starts. The error log shows:

2016-01-13 08:01:48 7fbc00133700 InnoDB: uncompressed page, stored checksum in field1 2912050650, calculated checksums for field1: crc32 1490770609, innodb 1549747911, none 3735928559, stored checksum in field2 1670385167, calculated checksums for field2: crc32 1490770609, innodb 2416840536, none 3735928559, page LSN 0 130051648, low 4 bytes of LSN at page end 1476903022, page number (if stored to page already) 4651, space id (if created with >= MySQL-4.1.1 and stored already) 7
InnoDB: Page may be an index page where index id is 22
InnoDB: (index "PRIMARY" of table "test"."t")
InnoDB: Database page corruption on disk or a failed
InnoDB: file read of page 4651.
InnoDB: You may have to recover from a backup.
InnoDB: It is also possible that your operating
InnoDB: system has corrupted its own file cache
InnoDB: and rebooting your computer removes the
InnoDB: error.
InnoDB: If the corrupt page is an index page
InnoDB: you can also try to fix the corruption
InnoDB: by dumping, dropping, and reimporting
InnoDB: the corrupt table. You can use CHECK
InnoDB: TABLE to scan your table for corruption.
InnoDB: See also http://dev.mysql.com/doc/refman/5.6/en/forcing-innodb-recovery.html
InnoDB: about forcing recovery.
InnoDB: Database page corruption on disk or a failed
InnoDB: file read of page 4651.
InnoDB: You may have to recover from a backup.
2016-01-13 08:01:48 7fbc00133700 InnoDB: Page dump in ascii and hex (16384 bytes):
 len 16384; hex ad925dda0000122b0000122affffffff0000000007c06e4045bf00000000000000000
[...]

OK, our database is corrupted and it is printing the page dump in ASCII and hex. Usually, the recommendation is to recover from a backup. In case you don’t have one, the recommendation would be the same as the one given by the error log. When we hit corruption, first thing we should try is dumping the data and then re-importing to another server (if possible). So, how we can read a corrupted TABLE and avoid the crash? In most cases, the

innodb_force_recovery

  option will help us. It has values from 1 to 6. They are documented here:

http://dev.mysql.com/doc/refman/5.6/en/forcing-innodb-recovery.html

The idea is to start with 1. If that doesn’t work, proceed to 2. If it fails again, then go to 3 . . . until you find a value that allows you to dump the data. In this case I know that the problem is a corrupted InnoDB page, so a value of 1 should be enough:

“Lets the server run even if it detects a corrupt page. Tries to make SELECT * FROM tbl_name jump over corrupt index records and pages, which helps in dumping tables.”

We add

innodb_force_recovery=1

 and restart the service. Now it’s time to try and dump our data with

mysqldump

. If the corruption is even worse you need to keep trying different modes. For example, I have this error:

> create table t2 like t;
> insert into t2 select * from t;
ERROR 1034 (HY000): Incorrect key file for table 't'; try to repair it
> insert into t2 select * from t;
ERROR 1712 (HY000): Index t is corrupted

innodb_force_recovery=1

 doesn’t work here. It doesn’t allow me to dump the data:

# mysqldump -uroot -pmsandbox --port 5623 -h 127.0.0.1 --all-databases > dump.sql
Error: Couldn't read status information for table t ()

but in my test server, it seems that

innodb_force_recovery=3

  helps.

This procedure sounds good and usually works. The problem is that the feature is mostly broken after 5.6.15.

innodb_force_recovery

 values greater or equal 4 won’t allow the database to start:

2015-07-08 10:25:25 315 [ERROR] Unknown/unsupported storage engine: InnoDB
2015-07-08 10:25:25 315 [ERROR] Aborting

Bug are reported and verified here: https://bugs.mysql.com/bug.php?id=77654

That means that if you have Insert Buffer, Undo Log or Redo log corruption (values 4, 5 and 6) you can’t continue. What to do?

  • You can install a older version of MySQL (previous to 5.6.15) to use higher values of
    innodb_force_recovery

    . Modes 4, 5 and 6 can corrupt your data (even more) so they are dangerous. If there are no backups this is our only option, so my recommendation would be to make a copy of the data we have now and then proceed with higher values of

    innodb_force_recovery

    .

or

  • If you are using Percona Server,
    innodb_corrupt_table_action

      can be used to dump the data. You can use the value “salvage”. When the option value is salvage, XtraDB allows read access to a corrupted tablespace, but ignores corrupted pages.

https://www.percona.com/doc/percona-server/5.6/reliability/innodb_corrupt_table_action.html

If you can’t still dump your data, then you should try more advance solutions like Undrop for InnoDB. Also, it would be good idea to start planning to create regular database backups.    :)

Read more at: http://www.mysqlperformanceblog.com/

MongoDB revs you up: What storage engine is right for you? (Part 3)

MongoDBDifferentiating Between MongoDB Storage Engines: RocksDB

In this series of posts, we discussed what a storage engine is, and how you can determine the characteristics of one versus the other:

“A database storage engine is the underlying software that a DBMS uses to create, read, update and delete data from a database. The storage engine should be thought of as a “bolt on” to the database (server daemon), which controls the database’s interaction with memory and storage subsystems.”

Generally speaking, it’s important to understand what type of work environment the database is going to interact with, and to select a storage engine that is tailored to that environment.

The first post looked at MMAPv1, the original default engine for MongoDB (through release 3.0). The second post examined WiredTiger, the new default MongoDB engine.

This post will cover RocksDB. RocksDB builds on LevelDB, Google’s open source key value database library. It was designed to address several scenarios:

  1. Scale to run on servers with many CPU cores.
  2. Use fast storage efficiently.
  3. Be flexible to allow for innovation.
  4. Support IO-bound, in-memory, and write-once workloads.

RocksDB

Find it in: Percona Builds

RocksDB, designed originally at Facebook, uses LSM trees to store data, unlike most other storage engines which are using B-Trees.

LSM trees are designed to amortize the cost of writes: data is written to log files that are sequentially written to disk and never modified. Then a background thread merges the log files (compaction) into a tree like structure. With this design a single I/O can flush to disk tens or hundreds of write operations.

The tradeoff is that reading a document is more complex and therefore slower than for a B-Tree; because we don’t know in advance in which log file the latest version of the data is stored, we may need to read multiple files to perform a single read. RocksDB uses bloom filters and fractional cascading to minimize the impact of these issues.

As far as workload fit, RocksDB can provide very good insert and query performance while providing compression ratios that are typically better than wiredTiger and slightly worse than PerconaFT. Also, RocksDB is theoretically better than PerconaFT at keeping up with the frequent and heavy delete workloads that accompany TTL indexes in high insert workloads.

Percona is excited to offer enterprise support for RocksDB! RocksDB as part of our MongoDB support options: https://www.percona.com/services/support/rocksdb-support.

Conclusion

Most people don’t know that they have a choice when it comes to storage engines, and that the choice should be based on what the database workload will look like. Percona’s Vadim Tkachenko performed an excellent benchmark test comparing the performances of, PerconaFT and WiredTiger to help specifically differentiate between these engines.

In Part Four of this blog series, we’ll take a closer look at Percona’s MongoDB storage engine: PerconaFT.

Part 1: Intro and the MMAPv1 storage engine.

Part 2: WiredTiger storage engine.

Read more at: http://www.mysqlperformanceblog.com/

Tired of MySQL Making You Wait? Webinar: Questions and Answers

MySQLWe’d like to thank everybody for joining us on January 7th for our “Tired of MySQL Making You Wait?” webinar with Percona’s Alexander Rubin, Principal Consultant and SolarWinds’ Janis Griffin, Database Evangelist.

Too often developers and DBAs struggle to pinpoint the root cause of performance issues and then spend too much time in trying to fix them. In the webinar, we discussed how you can significantly increase the performance of your applications while also reducing database response time.

You can find an archived version of the webinar here.

Below are the questions that were asked during the webinar, with responses from Alex and Janis. If you need further clarification, please respond in the comments.

Thanks again, and we look forward to you joining us at our next webinar (with Percona CEO Peter Zaitsev), Compression In Open Source Databases!



Q: Are there special tuning tips for Galera Cluster?

A: Since Galera Cluster (Percona XtraDB Cluster) is based on MySQL, all query tuning tips will apply as well. There are a number of Galera Cluster configuration tips available: for example the blog post at this link talks about tuning the PXC for maximum write throughput: https://www.percona.com/blog/2015/06/03/optimizing-percona-xtradb-cluster-write-hotspots/



Q: Does DPA support Galera Cluster ?

A: Yes, DPA has the ability to group the cluster together to see load balancing, top 15 SQLs across the cluster, plus the top wait states.



Q: Can I create a covered index when I have “group by” and “order by” instructions together?

A: Yes, you can create a covered index and MySQL will use it to satisfy the query (you will see “using index”). If you have “group by” and “order by” on a different columns, however, MySQL will still have to perform a filesort and create a temp table. To create this index, specify all the following fields in your query in the index:

  1. All fields in the “where” condition
  2. The “group by” fields
  3. The “order by” fields
  4. The fields that the query is selecting.

Please note the limitations of such approach described here: http://dev.mysql.com/doc/refman/5.7/en/order-by-optimization.html



Q: Can we use DPA with Azure MySQL?

A: Yes, DPA will monitor, tune and analyze the SQL server performance running on Microsoft Azure.



Q: Do you know if MariaDB has or is planning to follow with these virtual fields and/or SYS schema enhancements from MySQL 5.7?

A: MariaDB has had virtual or computed columns since version 5.2. I don’t believe MariaDB comes with the sys schema already installed, but you can download and install it.



Q: Does DPA support PostgreSQL? If not, is it in the roadmap?

A: Currently, DPA does not support PostgresSQL. However, we continually re-evaluate it with each new release.



Q: Does DPA support RDS instances?

A: Yes, DPA supports the monitoring of RDS instances.



Q: Does the performance schema show any information about how the load data is performing?

A: MySQL 5.5 performance_schema became available in 5.5.3 and has only 11 tables. Most of the tables deal with wait events and file information. In addition, you would need turn on the consumers and enable the instrumentation of the wait events. Once you’ve done that, you will be able to see the threads and what they are waiting on.



Q: I didn’t understand the reasoning that leads to the index on ORDER BY. I can’t link it to the previous slide query.

A: I assume this question is about the ORDER BY + LIMIT optimization. When you create an index on the ORDER BY field only, MySQL can start reading the whole table in the order of the index. As the index is sorted, it can start fetching the rows and filter out the rows that don’t match the ORDER BY condition. As there is a LIMIT N on the query, MySQL will stop after fetching N rows.



Q: How can I analyze parts of a stored procedure that runs nightly to see where by bottlenecks are? It has 100+ update queries that it performs every night to build a table with one million plus rows.

A: You can do it using the slow query log in Percona Server (5.5/5.6) and/or Performance Schema in MySQL 5.7. If you are running Percona Server, you can enable extended stored procedures logging as described here: https://www.percona.com/doc/percona-server/5.6/diagnostics/slow_extended.html. Another way is using a deprecated “show profile” method as described here: https://www.percona.com/blog/2009/01/19/profiling-mysql-stored-routines/



Q: How will DPA use the index when there are more than five columns in the “where” conditions? How would you create indexes?

A: I would suggest checking the “cardinality” of the fields (= number of unique values). Usually (unless you create a covered index or are optimizing the group by) it makes much more sense to limit the number of fields in an index, and only include the fields with the high cardinality. For example, PRIMARY KEY or UNIQUE INDEX works best, whereas the “gender” field (with only two unique values, “male” and “female”) would not be very useful.



Q: How would the analytics tool work in an open stack VM environment, where we have 100 database servers?

A: One installation of DPA can monitor hundreds of database servers. In fact, we have several very large companies that monitor 1000s of servers worldwide.



Q: If you have a small table with only 100 records, is it worth creating indexes on specific fields or just do a table scan?

A: If the table is only 100 records and you are not joining it with other tables, it usually does not make sense to add indexes. But because the table is so small it doesn’t really matter either way.



Q: Is the SolarWinds tool better than MONyog, and how expensive is the license cost for this?

A: MONyog is also a monitoring tool, but it doesn’t have the advisors, alarms, granularity, history, or customizations that DPA gives you. The retail cost per server is currently $1,995 per monitored server, but is heavily discounted the more you purchase.



Q: In many cases, due to the randomness and complexity of queries thrown at various tables, I end up creating a lot of indexes. At what point would there be too many indexes? Should I then create MySQL views instead of indexes? Should one use MySQL views at all to optimize searches?

A: First of all there are no “materialized views” in MySQL, so it is not a useful replacement for indexes. You can create “summary” tables manually, which will usually help a lot. Although it is hard to say when you have too many indexes, lots of indexes can decrease the performance of your insert/update/delete operations, as well as confuse MySQL. So a great many indexes might cause MySQL to start choosing a wrong index when doing selects.



Q: Sometime, we need to add indices for different queries for the same table. Eventually, the table has too many indices. Any suggestion for such cases?

A: See the response to the previous question.



Q: Is there a way in DPA to see what queries are currently running? In other words, to know about slow queries as they run rather than only knowing about them historically?

A: Yes. In the “Current” dashboard, click the “Currently Active Sessions” box. With this option, you can sort by longest running, etc.



Q: Why is delay indexed in the composite key? It only covers the query, but the temp table can be avoided by the first two fields?

A: You are referring to this example:

mysql> alter table ontime_2012
add key covered(dayofweek, Carrier, DepDelayMinutes);
explain select max(DepDelayMinutes), Carrier, dayofweek from ontime_2012 where dayofweek =7 group by CarrierG
...
possible_keys: DayOfWeek,covered
          key: covered
          key_len: 2
          ref: const
          rows: 905138
          Extra: Using where; Using index

The reason we add DepDelayMinutes is to make the index covered, so MySQL will be able to satisfy the query with an index only.



Read more at: http://www.mysqlperformanceblog.com/
